BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounder
2  E4 - 1 - 144 - 0 - 1727½Taylor in 1923

Inscriptions:



Trapezoids
How does the shape of this bell compare to others in the ring?
Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.
Photos
Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Upper Octave261420
Upper Quint1915-21
Upper Third1598-18
Nominal12920
Quint97411
Tierce7728
Prime6485
Hum3245

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:1291Hz
Flat of E6 by 28Hz.
MP3
Stony_2.mp3
