BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounderMP3
3  A2 - 1 - 172 - 1 - 421½Taylor in 1992

Inscriptions:

Te Deum Laudamus
Reginald Hereford Bird - Vicar
James Farr - Churchwarden 1902


Trapezoids

How does the shape of this bell compare to others in the ring?


Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.

Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Hum440-1
Prime8823
Tierce1038-15
Quint134635
Nominal17610
Upper Third224131
Upper Quint2634-5
Upper Octave362248

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:1761Hz
Sharp of A by 1 cents
