Corrections to analysis of bell harmonics at Wavendon and Great Linford - June 2022


BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounderMP3
5  A - - 7 - 2 - 1535¼Taylor Oxford in 1839

Inscriptions:

W : & : J TAYLOR BELL FOUNDERS OXFORD : 1839


Trapezoids

How does the shape of this bell compare to others in the ring?


Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.

Photos
 Removal of the bells
Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Hum22435
Prime4390
Tierce52613
Quint652-15
Nominal8780
Upper Third1088-15
Upper Quint1304-17
Upper Octave178932

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:878Hz
Flat of A by 2 cents
