Corrections to analysis of bell harmonics at Wavendon and Great Linford - June 2022


BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounderMP3
8D#Weight BoardD#/Eb21 - 2 - 1623 - 3 - 1649Gillett & Johnston in 1911

Inscriptions:

RECAST BY GILLETT & JOHNSTON CROYDON 1911.
NUNTIA SUM COEPTAE PERITURAE
PRAEVIA VITAE. ET MODO TRANSACTAE
VOX EGO CERTA TUAE.
THE REVḌ CHARLES KIPLING. VICAR
WILLIAM WHITE EDWARD CLEAVER CHURCH WARDENS 1819.
T. MEARS OF LONDON FECIT.


Trapezoids

How does the shape of this bell compare to others in the ring?


Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.

Photos
 Front Page Advert
12
Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Hum1540
Prime3080
Tierce38168
Quint4622
Nominal6160
Upper Third768-4
Upper Quint900-46
Upper Octave1220-17

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:616Hz
Flat of D#/Eb by 6 cents
