Corrections to analysis of bell harmonics at Wavendon and Great Linford - June 2022


BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounderMP3
2  F#/Gb - - 3 - 1 - 2425⅜Wesley in 2019

Inscriptions:

WESTLEY 20 O 19 GROUP
GIVEN BY
MARGARET LINDSAY HOOTON
IN MEMORY OF HER PARENTS
### LINDSAY AND HIS DEARLY LOVED WIFE JANET


Trapezoids

How does the shape of this bell compare to others in the ring?


Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.

Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Hum3800
Prime7600
Tierce902-3
Quint114611
Nominal15200
Upper Third1848-48
Upper Quint2252-21
Upper Octave30485

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:1520Hz
Sharp of F#/Gb by 40 cents
