BellDocumented NoteDocumented Note SourceRecorded NoteRecorded WeightEstimated WeightDiameterFounder
3  B - - 7 - 0 - 1433¼Bartholomew Atton in 1594

Inscriptions:

BARTHOLOMEWE # ATTVN + 1594 #
O O

Trapezoids
How does the shape of this bell compare to others in the ring?
Here, the shape of all the bells are compared by reducing their size so they all have the same radius at the soundbow.
Then we can see if the founder made bells taller, wider or the same shape as different sized bells were created.
Photos
Photos
 3rd bearing
123456789
Tonal Analysis
Is this bell in tune with itself?
ToneFrequency (Hz)Tuning
Hum248-21
Prime468-121
Tierce5996
Nominal10040
Upper Third1229-36
Upper Quint1498-9
Upper Octave205439

This shows each harmonic relative to what it should be relative to the Nominal
taking Simpson Tuning as an ideal.
A positive figure shows that the harmonic is sharp, a negative figure shows that it is flat. There are 100 cents between notes on the scale.
Nominal:990Hz
Sharp of B5 by 2Hz
MP3
Radclive3.mp3
